2 PACK Universal 12-40V 120W Unidirectional PWM DC Motor Controller Speed Regulator Switch
✔ Worldwide free shipping on orders over $14.99 !
✔ Free gift message card: Yes
✔ Corporate bulk purchasing: Yes
✔ Dropshipping services: Yes
✔ Customized packaging: Yes
✔ OEM ODM orders: Yes
For any special requests, feel free to contact us anytime. We're here to help!
Adding to cart succeed
2 PACK Universal 12-40V 120W Unidirectional PWM DC Motor Controller Speed Regulator Switch
color:red,size:xxl
Subtotal: US$ 0
View My Cart
-
- Product Name: 2 PACK Universal 12-40V 120W Unidirectional PWM DC Motor Controller Speed Regulator Switch
- Item NO.: 2555686
- Weight: 0 kg = 0.0000 lb = 0.0000 oz
- Category: Cool Gadgets
- Tag: DC Motor Pump , Motor Speed Controllers , PWM Speed Controller
- Brand: VEASOON
- Creation Time: 2024-09-07
Product Description:
★Upgraded 12-40V 10A DC Motor Pump PWM Speed Controller and PLC voltage can be directly controlled.
★Its own power supply reverse polarity protection, control voltage over-voltage protection, 20A fast-blow ceramic fuse.
★Adjust the order of the cable to change the orientation，can control motor speed to change from 0 percent to 100 percent.
★Adjust the knob of potentiometer to change the output occupying Vacancy proportion of controller, and the motor speed will change.
★Rated Current: 5A, Max Current: 10A, Quiescent Current: 0.005A (Standby).
Parameter:
Input voltage: DC 10V-30V
Control power: 120W Max
Rated current： 5A
Maximum current：10A
Speed adjustment range: 0%-100%
PWM frequency: 13kHz
Potentiometer: resistance value B10K; wire length 20cm; opening 8mm
Size: 60mm*47mm*28mm
Weight: 47g
Package include:
2 x A DC 10-40V PWM Unidirectional controller
Note:
If you need to control the forward and reverse, the customer can connect the positive and negative switch.
Equipped with 10A fuse (5 mm*20 mm size), power supply reverse connection protection, overvoltage and over current protection.
